Product Summary
The LH28F008SCB-L85 Flash memory with SmartVoltage technology is a high-density, low-cost, nonvolatile, read/write storage solution for a wide range of applications. Its enhanced suspend capabilities provide for an ideal solution for code + data storage applications. For secure code storage applications, such as networking, where code is either directly executed out of flash or downloaded to DRAM, the LH28F008SCB-L85 offers three levels of protection: absolute protection with VPP at GND, selective hardware block locking, or flexible software block locking.
Parametrics
LH28F008SCB-L85 absolute maximum ratings: (1)Operating Temperature: During Read, Block Erase, Byte Write and Lock-Bit Configuration: 0°C to +70°C, Temperature under Bias:-10°C to +80°C, Storage Temperature: -65°C to +125°C; (2)Voltage On Any Pin (except VCC, VPP, and RP#): -2.0V to +7.0V; (3)VCC Supply Voltage: -2.0V to +7.0V; (4)VPP Update Voltage during Block Erase, Byte Write and Lock-Bit Configuration: -2.0V to +14.0V; (5)RP# Voltage with Respect to GND during Lock-Bit Configuration Operations: -2.0V to +14.0V; (6)Output Short Circuit Current: 100mA.
Features
LH28F008SCB-L85 features: (1)SmartVoltage Technology; (2)Enhanced Suspend Capabilities; (3)In-System Block Locking.
Diagrams
 |
